Evo High Beam Spotlights Black Sw-Motech NSW.00.490.10101
The EVO high-beam headlights' well-focused light has a particularly wide beam. This provides optimal illumination of the field of vision, increasing safety on and off the road. To develop the new EVO headlights, SW-MOTECH sought a strong partner and relied on the expertise of a long-standing automotive manufacturer. The focus was on a compact design and compliance with the highest quality standards: the EVO high-beam headlights are waterproof and dustproof to IP69 protection. The virtually wear-resistant LEDs used in these premium headlights ensure years of optimal visibility.
Technical Data Sheet:
- Trouble-free and maintenance-free operation thanks to the almost wear-free LED, with significantly reduced energy consumption
- Power: 12W each spotlight
- Luminous flux: 800 LM each spotlight
- ECE control mark: ECE R113 Rev.2
- Light with narrow focus and long distance illumination
- Compact size with a diameter of 7.1 cm
- Waterproof and dustproof (protection class: IP69)
- Voltage: 12 V. Wiring harness is included for easy connection to the motorcycle battery, it is not no modifications to the motorcycle's electrical circuit are required
- Splash-proof handlebar switch with blue indicator light for comfortable use (protection class: IPX4)
- Fixing points on all four sides
- Mounting on the headlight clamps for tubular protectors (diameter 22, 26, 27, 28 mm) or on model-specific brackets
Contents of the shipment
- 2 x EVO spotlights
- 1 x Handlebar Switch
- Assembly instructions
- Assembly material
Details
- Material: Aluminum
- Surface: powder coated
- Color: black
- Total weight: approx. 1.3 kg
I notify
- Remember that the "TOP" marking must always be at the top, due to the curvature of the reflector.
- Spotlight clamps for tubular protectors and model-specific brackets are available separately
- Please observe the legal regulations in force in your country for the operation and installation of high beams.
Required for installation
- Clamps for tubular protectors or model-specific spotlight support
Approval Notice
The spotlights are equipped with the ECE test mark (ECE R113 Rev. 2). The ECE numbers allow installation without further approval from a testing institute such as TUV or DEKRA.Motorcycle lighting is regulated at the national level in the Federal Republic of Germany by the StVZO (German Road Traffic Licensing Regulation) (§ 50) and at the European level by Directive 93/92 EEC relating to lighting and signalling devices on two- and three-wheeled vehicles. These regulations and directives state, among other things, that: - the installation of two high beam headlights is permitted. - in the case of two high beam headlights, the distance between the two illuminating surfaces must not exceed 200 mm. - the white light is intended for front lighting and the red light for rear lighting, while the yellow light can be used on the sides. - the pairs of lights must be fixed symmetrically with respect to the centre of the vehicle and at the same height. - the brightness of the lamps must be the same.- the low beam headlights must not be operated simultaneously with the fog lights. Before purchasing the product, it is necessary to check the approval regulations in force in the respective country.
